Tripp Lite B150-1A1-HDMI AV extender AV transmitter & receiver Black

Tripp LiteSKU: B150-1A1-HDMI

Price:
Sale price$117.77

We exclusively offer FedEx Ground Shipping for all your purchases with Startechtel.com. We promise speedy delivery, offering FedEx shipping, and getting your orders out the door as fast as possible (usually same day). We primarily ship using FedEx Ground service, however we reserve the right to ship any other standard (or other) method. Business-day standard shipping orders placed by 2:00 pm PST usually ship the same day.

Description

DisplayPort to HDMI over Cat5/6 Active Extender Kit, Pigtail Transmitter/Receiver for Video/Audio, 150 ft. (45 m), TAA

Key Features

  • Extends 1080i signal up to 150-ft. (45.72 m), 1080p signal up to 125-ft. (38.1 m)
  • Supports 24-bit True Color (8 bits per channel) and stereo audio
  • Included USB Micro-B cables supply power to both units
  • Works with all operating systems
  • Plug and play—no software or drivers to install
  • HDCP 1.3 compliant
  • Built-in HDMI cable latches tightly for more secure connection

Description

The B150-1A1-HDMI DisplayPort to HDMI over Cat5/Cat6 Active Extender Kit includes a transmitter unit and a receiver unit that work in tandem to convert a DisplayPort audio/video signal to HDMI and then extend it to a projector, monitor or television up to 150 feet (45.7 meters) away. The kit is ideal for digital signs, trade shows, presentations, classrooms, churches, retail settings and other applications where the video source is located farther than convention cables allow.

One Cat5e/6 cable connects the transmitter and receiver (for best results, use 24 AWG solid-wire Cat5e/6 cable, such as the N202-Series). A built-in DisplayPort cable connects the transmitter to the source, while a built-in HDMI cable connects the receiver to the display. The built-in HDMI cable features a latching connector that helps prevent accidental disconnection. Included USB Micro-B cables connect the transmitter to a USB port on the DisplayPort computer or a USB wall charger (such as U280-002-W12), and connect the receiver to a USB port on the HDMI display or a USB wall charger. No external power supplies are needed.

The B150-1A1-HDMI can extend a high-definition 1080i (60 Hz) signal up to 150 feetand a 1080p (60 Hz) signal up to 125 feet (38.1 meters). In addition to crystal-clear video, including 24-bit True Color (8 bits per channel), the kit delivers full, rich stereo. Green and orange LEDs on both units indicate when they are receiving power from the USB Micro-B cables and sharing a signal. Easy to set up with no software or drivers to install. Works with all operating systems.

Specifications

Features
Colour depth 24 bit
Plug and Play Yes
Certification TAA
Type AV transmitter & receiver
Maximum resolution 1600 x 1200 pixels
Cable types supported Cat5, Cat6
Maximum transfer distance 1771.7" (45 m)
Supported video modes 480i, 480p, 720p, 1080i, 1080p
Supported graphics resolutions 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1440 x 900, 1600 x 1200 (UXGA)
Product colour Black
Ports & interfaces
USB ports quantity 2
USB connector type USB Type-A
RJ-45 input ports 2
HDMI in 1
Packaging data
Package depth 5.59" (142 mm)
Package width 7.87" (199.9 mm)
Package height 1.73" (43.9 mm)
Package weight 7.76 oz (220 g)
Packaging content
Cables included Micro-USB
Manual Yes
Technical details
Country of origin Taiwan
Quantity 1
Compliance certificates RoHS
Logistics data
Master (outer) case width 17.9" (455.9 mm)
Master (outer) case length 8.39" (213.1 mm)
Master (outer) case height 6.02" (152.9 mm)
Master (outer) case gross weight 5.4 lbs (2.45 kg)
Products per master (outer) case 10 pc(s)
Master (outer) case GTIN (EAN/UPC) 10037332190113
