Tripp Lite B122-000 AV extender AV repeater

Tripp LiteSKU: B122-000

Price:
Sale price$12.87

We exclusively offer FedEx Ground Shipping for all your purchases with Startechtel.com. We promise speedy delivery, offering FedEx shipping, and getting your orders out the door as fast as possible (usually same day). We primarily ship using FedEx Ground service, however we reserve the right to ship any other standard (or other) method. Business-day standard shipping orders placed by 2:00 pm PST usually ship the same day.

Description

HDMI Signal Booster / Extender, 1920 x 1200 (1080p) 24Hz, Up to 150 ft. (45 m), (HDMI F/F),TAA

Key Features

  • Extend a 1080p @ 24Hz (or 1920 x 1200) HDMI signal up to 150-ft. (45.72 m) from the source
  • When extending a 1080p @ 24Hz (or 1920 x 1200) signal more than 75-ft. (22.86 m), use cable made with 24Awg wiring, such as the P568-100-HD
  • No external power required in most installations
  • 24Awg HDMI cable is also needed when extending a 3D signal more than 50-ft. (15.24 m). A 3D signal can be extended up to 125-ft. (38.1 m) using 24Awg HDMI cable
  • Supports DTS-HD, Dolby True HD and 7.1 Channel Surround Sound Audio
  • Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

Description

The B122-000 HDMI Signal Extender increases the distance a 1080p at 24 Hz (or 1920 x 1200) signal can be transmitted beyond the recommended 16 feet (4.9 meters). It supports computer video resolutions up to 1920 x 1200 and HD resolutions up to 1080p at 24 Hz, as well as a maximum distance of 150 feet (45.7 meters) from the source. Use P568-Series HDMI cables in most applications. When extending a 1080p at 24 Hz (or 1920 x 1200) signal more than 75 feet (22.9 meters), use cable made with 24 AWG wiring, such as the P568-100-HD. 24 AWG HDMI cable is also needed when extending a 3D signal more than 50 feet (15.2 meters). A 3D signal can be extended up to 125 feet (38.1 meters) using 24 AWG HDMI cable. Simply connect the longer cable between the source and the B122-000 and the shorter cable (16 feet or less) between the adapter and the monitor. Software or drivers are not required. HDCP compliant. Compatible with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Specifications

Features
Type AV repeater
Maximum resolution 1920 x 1200 pixels
Cable types supported Cat5, Cat5e
Maximum transfer distance 1800" (45.7 m)
Audio system Multichannel
Supported video modes 1080p
Ports & interfaces
HDMI in 1
Number of HDMI outputs 1
DC-in jack Yes
Packaging data
Package depth 6" (152.4 mm)
Package width 4.6" (116.8 mm)
Package height 1.3" (33 mm)
Package weight 4.94 oz (140 g)
Technical details
Country of origin Taiwan
Logistics data
Master (outer) case width 6.6" (167.6 mm)
Master (outer) case length 13.4" (340.4 mm)
Master (outer) case height 5.6" (142.2 mm)
Master (outer) case gross weight 25.7 oz (730 g)
Products per master (outer) case 10 pc(s)
Master (outer) case GTIN (EAN/UPC) 10037332133141
