Tripp Lite B119-4X1-MV video switch HDMI

Tripp LiteSKU: B119-4X1-MV

Price:
Sale price$218.18

We exclusively offer FedEx Ground Shipping for all your purchases with Startechtel.com. We promise speedy delivery, offering FedEx shipping, and getting your orders out the door as fast as possible (usually same day). We primarily ship using FedEx Ground service, however we reserve the right to ship any other standard (or other) method. Business-day standard shipping orders placed by 2:00 pm PST usually ship the same day.

Description

4x1 HDMI Multi-viewer with Remote Control - 1080p @ 60 Hz (HDMI 4xF/1xF)

Key Features

  • Can display video from one, two or all four HDMI sources at the same time
  • Included remote control allows you to toggle between display modes with ease
  • Transmits HD picture quality at 1080p video resolutions @ 60 Hz
  • Audio switches independently, so you can watch one video source and hear another
  • Plug-and-play operation with no software required for easy, immediate installation

Description

HDMI Quad-Screen Multi-Viewer Connects 4 Audio/Video Sources to One HDMI Display
This 4-input HDMI multi-viewer allows you to connect four separate HDMI audio/video sources to one HDMI television, projector or monitor, and then display the video feeds from all four at the same time. For instance, connect a media server, Blu-ray player, security camera and Xbox to your HDTV, and watch the video transmission from all four simultaneously with built-in IR control.
Recommended for Home Theaters, Digital Signage and Other Audio/Video Applications
This HDMI quad multi-viewer is ideal for home theater, digital signage, broadcasting, video conferencing and security monitoring, just to name a few applications. Plus, it helps you avoid the cost of buying additional displays for your source devices and save space by combining four monitors into one.
Choose from Quad, Dual or Full-Screen Mode at the Click of a Button
Use the push-button on the unit or the included remote control to select which mode to use. In addition to displaying all four video feeds simultaneously in Quad Mode, you can watch video from two source devices using Dual Mode or just one in Full-Screen Mode. Pressing another button on the unit lets you switch the audio feeds independently of the video, so you can watch video from one HDMI source and hear audio from another. The unit comes with 12 different preset display configurations.
Transmits Crystal-Clear Video up to 1080p for High-Definition Presentations
This HDMI multi-viewer ensures HD performance with video resolutions up to 1080p at 60 Hz (1920 x 1080).
Ready to Use Right from the Package, So You Can Plug and Play Immediately
The compact plug-and-play switch requires no software or drivers to download and install. Connect your devices to the HDMI ports with user-supplied HDMI cables (such as P568-Series), and plug the included external power supply (with four international plug adapters to ensure use all over the world) into an AC power source to get started. A red LED indicates the unit is receiving power, and blue LEDs indicate connected HDMI inputs.

Specifications

Ports & interfaces
Video port type HDMI
HDMI version 1.3
HDMI ports quantity 5
Number of HDMI outputs 4
HDMI in 1
DC-in jack Yes
Features
Heat dissipation 34.12 BTU/h
Product colour Black
Supported video modes 1080p
Plug and Play Yes
Maximum refresh rate 60 Hz
Material Iron
LED indicators Link, Power
HDCP Yes
Cable length 47.2" (1.2 m)
Country of origin China
HDCP version 1.2
Power
AC adapter input voltage 100 - 240 V
AC adapter frequency 50/60 Hz
AC adapter input current 0.6 A
AC adapter output voltage 12 V
AC adapter output current 2 A
Power consumption (typical) 10 W
Certificates
Certification CE, FCC, RoHS, REACH
Weight & dimensions
Width 4.07" (103.4 mm)
Height 5.85" (148.5 mm)
Depth 0.839" (21.3 mm)
Weight 12 oz (340 g)
Packaging data
Package type Box
Package width 7.83" (198.9 mm)
Package height 3.15" (80 mm)
Package depth 5.83" (148.1 mm)
Package weight 24 oz (680 g)
Packaging content
Plug adapter type NA, UE, UK, AU
Manual Yes
Remote control included Yes
AC adapter included Yes
Mounting kit Yes
Operational conditions
Storage temperature (T-T) -20 - 60 °C
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 20 - 90%
Technical details
Compliance certificates RoHS
Logistics data
Master (outer) case gross weight 30 lbs (13.6 kg)
Products per master (outer) case 20 pc(s)
Master (outer) case width 16.7" (424.9 mm)
Master (outer) case length 12.4" (315 mm)
Master (outer) case height 16.5" (420.1 mm)
Country of origin China
Master (outer) case GTIN (EAN/UPC) 10037332213997
