Description
4x4 HDMI Matrix Switch/Splitter with Video Wall Configuration, Remote Control and Multi-Resolution Support, 4K 60 Hz, HDR, 4:4:4
This compact unit splits a video signal for display on multiple monitors, projectors or televisions at the same time. Ideal for offices, conference rooms, lecture halls, trade shows, retail settings and other digital signage applications, this splitter supports video resolutions up to {MaxResolution}. It is compatible with all major operating systems. The plug-and-play splitter comes ready to connect right out of the package and requires no additional software.
Key Features
- Allows flexible control via front-panel buttons, IR remote, RS-232 commands or TCP/IP
- Features 2 operational modes: 4x4 matrix (seamless switch) and video wall
- Supports HDMI input/output with UHD resolutions up to 4K @ 60 Hz (4:4:4)
- Supports multi-resolution output to allow for combination of different display types
- Plug-and-play operation with no software required for easy, immediate installation
Description
Transmits Video to Multiple Displays SimultaneouslyThis compact unit splits a video signal for display on multiple monitors, projectors or televisions at the same time. Ideal for offices, conference rooms, lecture halls, trade shows, retail settings and other digital signage applications, this splitter supports video resolutions up to {MaxResolution}. It is compatible with all major operating systems. The plug-and-play splitter comes ready to connect right out of the package and requires no additional software.
Specifications
| Ports & interfaces | |
|---|---|
| Video ports quantity | 8 |
| Video port type | HDMI |
| Video out | 4x HDMI |
| Consumer Electronics Control (CEC) support | Yes |
| Connector contacts plating | Nickel |
| Cable length | 59.1" (1.5 m) |
| Features | |
| LED indicators | Yes |
| Housing material | Metal |
| Maximum refresh rate | 60 Hz |
| Maximum resolution | 3840 x 2160 pixels |
| HDCP | Yes |
| Product colour | Blue |
| 3D | Yes |
| Connector contacts plating | Nickel |
| Cable length | 59.1" (1.5 m) |
| HDCP version | 2.2 |
| High Dynamic Range (HDR) supported | Yes |
| Audio decoders | Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, DTS, DTS-HD Master Audio |
| Power | |
| Power consumption (typical) | 19.56 W |
| AC input voltage | 100 - 240 V |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Cables included | IR |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Video | |
| Maximum refresh rate | 60 Hz |
| Maximum resolution | 3840 x 2160 pixels |
| HDCP | Yes |
| 3D | Yes |
| Colour | |
| Product colour | Blue |
| Indication | |
| LED indicators | Yes |
| Technical details | |
| Housing material | Metal |
| Video out | 4x HDMI |
| Compliance certificates | RoHS, Federal Communications Commission (FCC), UKCA, CE |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
