TP-Link TL-WA3001 AX3000 Dual-Band Wi-Fi 6 Gigabit Access Point (New)

AX3000 Gigabit Wi-Fi 6 Access Point

• Gigabit WiFi 6 Speed for 4K Streaming – 3000 Mbps Dual Band WiFi for faster browsing, streaming and downloading, all at the same time.
• Flexible Deployment – Supports Passive PoE to carry electrical power and data simultaneously.
• Multiple Modes – Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs.
• Boosted Coverage – Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals.
• Captive Portal – Offers a designed portal page for heightened security and marketing.

The Next Generation of Wi-Fi is Upon Us
Wi-Fi 6 (802.11ax) could turn out to be the most significant advancement in Wi-Fi development, delivering a huge boost in speed and total capacity. Mainstream adoption of Wi-Fi 6 is inching ever closer with more and more AX clients available. It's the right time to upgrade your router to the newest generation of Wi-Fi!

Lightning-Fast AX3000 Dual Band Wi-Fi
Upgrade your home or office network with the latest-generation of dual band 802.11ax access point, which offers combined speeds of up to 3000Mbps and is perfectly suited to serve multiple devices at the same time. The 5GHz band is ideal for Ultra-HD streaming video and online gaming, while the 2.4GHz band is there for all of your everyday Internet needs, like sending email and browsing the Internet.

Gigabit-Class Wired Performance
The gigabit Ethernet port makes full use of gigabit-class bandwidth provided by a local ISP to ensure reliable network connections. It also provides an ultra-fast connection for wired devices such as PCs, IPTVs, and game consoles, etc.

Specifications

HARDWARE FEATURES
Interface
1 Gigabit Port (Supports Passive PoE)

Button
Power On/Off Button, WPS Button, Reset Button

External Power Supply
48V/0.5A

Antenna Type
4 Fixed High Performance Antennas

WIRELESS FEATURES
Wireless Standards
IEEE802.11b/g/n/ax 2.4 GHz, IEEE 802.11a/n/ac/ax 5 GHz

Frequency
2.4 GHz and 5 GHz

Signal Rate
2402 Mbps at 5 GHz, 574 Mbps at 2.4 GHz

Reception Sensitivity
5 GHz:
11ax HE20 MCS0:-97dBm, 11ac VHT20 MCS9:-73dBm, 11ax HE20 MCS11:-67dBm
11ax HE40 MCS0:-94dBm, 11ac VHT40 MCS9:-70dBm, 11ax HE40 MCS11:-63dBm
11ax HE80 MCS0:-91dBm, 11ac VHT80 MCS9:-66dBm, 11ax HE80 MCS11:-60dBm
11ac VHT160 MCS9:-63dBm, 11ax HE160 MCS11:-58dBm
2.4 GHz:
11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-73dBm, 11ax HE20 MCS11:-65dBm
11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS9:-69dBm, 11ax HE40 MCS11:-62dBm

Transmit Power
FCC: less than 23dBm(2.4GHz), less than 22dBm(5GHz)

Wireless Functions
Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control

Wireless Security
WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions

SOFTWARE FEATURES
Quality of Service
WMM
Operating Modes
Access Point, Range Extender, Client, Multi-SSID
System Tools
SNMP, Ping Watchdog
DHCP
Server, DHCP Client List
Protocols
IPv4, IPv6

OTHERS
Certification
FCC, RoHS

Package Contents
Wireless Access Point TL-WA3001
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
PoE Power Injector

System Requirements
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Environment
Operating Temperature: 0^oC to 40^oC(32^oF to 104^oF)
Operating Humidity: 10%to90% non-condensing

Item Dimension (L"xW"xH")
18 x 14 x 4

Weight
8.00 lb
