D-Link DWL-8620AP Wireless AC2600 Wave2 4X4 MU-MIMO Dual Band Unified Access Point (New)

The DWL-8620AP Wireless AC2600 Wave 2 Dual-Band Unified Access Point is specially designed for small to medium businesses or enterprises, providing unparalleled bandwidth and flexibility for administrators looking to deploy a medium to large scale Wi-Fi network utilising the cutting-edge speed of Wireless AC Wave 2. Not only can it operate in standalone mode, the DWL-8620AP can also be centrally managed by D-Link Wireless Controllers. Highly manageable and capable of blazing speeds, it integrates seamlessly into any existing network infrastructure and can be easily scaled to meet future demands.

Greater Speed and Connectivity
The DWL-8620AP leverages the full potential of 802.11ac Wave 2 to provide unparalleled connectivity with ultra-high combined data rates of up to 2,533 Mbps2. In addition, it supports Link Aggregation, which allows two Gigabit Ethernet ports to be linked together and act as a single port to double the available bandwidth and maximise the overall throughput of the access point.

MU-MIMO Technology
The DWL-8620AP supports MU-MIMO (Multi-User Multiple Input Multiple Output), which enables the device to simultaneously communicate with multiple clients using multiple antennas. This allows the access point to utilise the spectrum more efficiently and significantly increase the network capacity. The DWL-8620AP support 4 x 4 MU-MIMO to take full advantage of all streams to serve more wireless clients to dramatically improve wireless performance.

Easy to Install
The DWL-8620AP can be ceiling mounted or wall mounted to meet the needs of any wireless application. For additional flexibility, it has integrated Power over Ethernet (PoE) support, allowing the devices to be installed in areas where power outlets are not readily available.

Specifications

General
Wireless Interface
IEEE 802.11b/g/n 2.4 GHz wireless
IEEE 802.11/a/n/ac Wave 2 5 GHz wireless
MIMO
4 x 4
Data Rate
2.4 GHz - Up to 800 Mbps
5 GHz - Up to 1733 Mbps
Antenna
Internal omnidirectional antennas
2.4 GHz: 3 dBi
5 GHz: 4 dBi
Operating Frequency
2400 to 2483.5 MHz
5150 to 5850 MHz
Operating Channels
1 to 13 channels for 2.4 GHz band (per country code)
36 to 165 channels for 5 GHz band (per country code)
Ethernet Interface
2 x 10/100/1000BASE-T LAN port
Console Port
RJ-45

Functionality
Advanced Features
Auto Channel selection
802.1p Quality of Service (QoS)
Wireless Multimedia (WMM)
Wireless Distribution System (WDS)
Band steering
Airtime Fairness
LACP Link Aggregation
IEEE 802.11k Fast Roaming

Management
Operating Mode
Standalone mode
Managed mode - Centrally managed by D-Link Wireless Controller
Management Interfaces
Web-based User Interface (Web UI)
Telnet/SSH
Command Line Interface (CLI)
SNMP v1/v2c/v3

Security
SSID Security
Up to 32 SSIDs, 16 per radio
802.1Q VLAN
Station Isolation
Wireless Security
WPA/WPA2 Personal/ Enterprise
AES
TKIP
Detection and Prevention
Rogue and Valid AP Classification
Authentication
MAC Address Filtering

Physical
Power Supply
Supports 802.3at PoE PD on LAN 1 Port
External power adapter: 12 V DC 2.5 A (not included)
Power over Ethernet
IEEE 802.3at
Maximum Power Consumption
24.24 W
Enclosure
Bottom cover - plastic
Top cover - plastic
UL2043-certified chassis
Temperature
Operating: 0 to 40 ^oC (32 to 104 ^oF)
Storage: -20 to 65 ^oC (-4 to 149 ^oF)
Humidity
Operating: 10% to 90% non-condensing
Storage: 5% to 95% non-condensing
MTBF
463,255 hours
Certifications
CE
EN55032, EN55024, EN61000-3-2, EN61000-3-3, EN60601-1-2 (Medical electrical equipment), EN301489-1, EN301489-17, EN300328, EN301893
FCC
IC
cUL+UL
CB
RCM
NCC
BSMI
UL2043

Item Dimension (L"xW"xH")
12 x 12 x 4

Weight
5 lbs
